Hay Dryer Process

How to Dry Hay
1: Harvest Hay
Select fresh hay with proper maturity and remove rotten or unsuitable materials before drying.
2: Clean the Hay
Remove dust, soil, and impurities from the hay. For large production capacity, a professional cleaning machine is recommended.
3: Cut or Crush Hay
According to drying requirements, hay can be cut into suitable lengths to improve drying efficiency.
4: Put the Hay on the Tray
Spread the hay evenly on the tray with a thickness of about 5-10 cm, then place the trays into the drying chamber.
5: Hay Drying
Set the drying temperature to 60-70°C and humidity to about 10%-15%. Drying time is usually 6-8 hours depending on the moisture content and thickness of the hay.
6: Storage
After drying, hay should be packed and stored in a dry and ventilated environment to avoid moisture absorption and maintain feed quality. Vacuum or sealed packaging can better preserve nutrients and freshness.

【Video display – click to play】

Hay Dryer Introduction

Working principle of hay dryer
The hay heat pump dryer uses reverse Carnot cycle technology to absorb heat from the air and convert it into hot air for circulating drying inside the drying chamber. The moisture is automatically removed through the dehumidification system for efficient and uniform drying.
The hay drying machine can quickly reduce moisture while maintaining the color, nutrients, and fiber quality of hay. Equipped with an intelligent control system, it realizes automatic temperature and humidity control.
The drying temperature range is 20-80°C, suitable for drying hay, alfalfa, forage grass, straw, animal feed, grains, herbs, and other agricultural materials.

Components of hay dryer:
Hay dryer includes a heat source, feed conveyor, air intake system, discharge conveyor, electronic control system, and drying host.

Advantages of the Hay Dryer

1. High Drying Quality: The dried hay retains its natural green color and nutrients, making it ideal for animal feed storage.
2. Fast Dehydration: The drying time for each batch of hay is typically 4-8 hours, depending on the raw material and moisture content.
3. Wide Application: Suitable for drying hay, alfalfa, forage, straw, silage, animal feed, grains, herbs, medicinal plants, and other crops.
4. Energy Saving and Environmentally Friendly: This machine utilizes heat energy from the air for drying, saving approximately 70% of operating costs.
5. Easy Operation: Fully automatic intelligent control system, easy installation, and low labor costs.

Technical parameters of chili dryer

Application of Hay Dryer

The mesh belt dryer machine is suitable for spice series, chili series, pharmaceutical series, agricultural and sideline products of large-scale continuous dehydration drying. It is an ideal choice for large enterprises to dry hay, spices, chilis, flowers, meat, pet snacks, herbs, nuts, seeds, and seafood.
